Aero Dyne Sound Control Company has been a trusted name in the HVAC industry for over 50 years. We specialize in manufacturing our High Efficiency Profile (H-E-P) Turning Vane and Rail System, designed specifically for commercial HVAC installations. Our products address the difficult challenges of inefficient airflow inefficiencies and noisy ducts, reducing sound power and pressure loss to the lowest possible levels.
H-E-P Turning Vanes
The High Efficiency Profile (H-E-P) Turning Vane and Rail System is used in HVAC systems to smoothly redirect airflow within ductwork, by minimizing turbulence and pressure loss, resulting in more efficient air distribution and reduced noise levels, often specified for projects requiring high performance airflow like hospitals and entertainment centers.
Based on results from the ETL Testing Laboratories, Inc. report no. 48037, Aero Dyne H-E-P Turning Vanes are certified for performance. The High Efficiency Profile design lowers relative pressure loss and reduces generated sound power to the lowest level attainable. Our design geometry adapts perfectly to all duct sizes, eliminating the need for two different vane sizes in the system. No other Turning Vane provides comparable quality, structural integrity, and performance for commercial HVAC installations.
Engineers
For over four decades, engineers have specified Aero Dyne Turning Vanes & Rail requesting NO SUBSTITUTIONS because of the H-E-P quality, structural integrity, and performance.
Contractors
Assembly is Quick, Easy & Positive. The exclusive method provides rigid, rattle proof assemblies at the Lowest Possible Cost.
Our Performance Matters
- Fast Turnaround – Typically ships within 24-48 hours of purchase order.
- Direct Seller – Establish an account with us today, pay by credit card or ask about our distributors.
- Prompt Customer Service – Quick and courteous response times to all inquiries.
Why Engineers and Contractors Choose Aero Dyne
Aero Dyne has been the preferred choice for HVAC design engineers and contractors for more than 50 years. Consulting engineers specify our products for commercial HVAC installations, knowing our vanes will meet rigorous performance standards. Many projects with a focus on high-performance, sustainable design have requested Aero Dyne by name, with “No Substitutions” written into the specifications. Our turning vanes have been installed in thousands of projects, including schools, hospitals, museums, performing arts centers and any project where performance is a priority.
Technical Benefits:
- Sound Performance: Aero Dyne H-E-P generated sound power levels do not exceed 54 decibels in band 4 at 2,000 fpm (24″x24″ duct size), a requirement for many engineers.
- Manufacturing Excellence: Aero Dyne products are manufactured in the USA, with steel sourced mainly from North American steel mills. Our manufacturing process adheres to strict standards and is certified under ISO 9001:2008.
- Efficiency: The True Airfoil Contour design of Aero Dyne vanes reduces relative pressure loss to the lowest level attainable, which results in lower fan horsepower requirements, leading to operational cost savings year-round.
Product Description:
The H-E-P Turning Vane and Rail System has three essential components: the airfoil blade, vane side rail, and fasteners. Performance may be compromised if assemblies are made without genuine Aero Dyne Side Rails.
- 3″ Radius Airfoil Blade: Engineered using a 17-point roll-forming process using one-piece 27GA HD Prime Carbon Galvanized Steel.
- Vane Side Rail: Constructed from 24GA HD Galvanized steel, with assembly slots located on design center spacing of 2.4 inches.
- Fasteners: Ring Shank style screws fasten into continuous channels inside the blade, Providing rigid, rattle-proof assemblies, eliminating need for reinforcing rods.
Proven Quality and Durability
Unlike standard turning vanes, Aero Dyne vanes are laboratory-tested and certified for performance. We have been committed to providing the best turning vane available in the market for over 50 years. The 17 point precision roll-forming process creates our proprietary continuous fastening tubes that prevent distortion and fluttering under air flow, providing unmatched reliability in commercial HVAC installations.
Request Your Free Engineer's Kit
Aero Dyne offers a free digital Engineer’s Kit, which includes detailed specifications, performance comparisons, and CAD details.
Engineer’s Kit Includes:
- The High Efficiency Profile (HEP) Turning Vane Brochure
- Suggested Specifications (.doc format) Section 233300 or 15890
- Turning Vane CAD Detail (.dwg) for your master CAD detail library or drawings
- Performance Comparison – (.pdf) H-E-P vs. standard vanes
- Submittal Form (.pdf)
- Case Study- H-E-P replaces 2″ double wall that results in annual cost savings
Request your kit today to discover how our H-E-P Turning Vanes can improve the efficiency and sound control performance in your next HVAC design project.
Quiet - Efficient - Reliable. Elevate Your HVAC Design with Aero Dyne!
Ready to improve the performance and efficiency of your HVAC system? Contact Aero Dyne Sound Control Company today to learn how our High Efficiency Profile Turning Vanes can help you achieve superior airflow, reduce noise, and optimize energy savings. Let us be your trusted partner in delivering high-quality, reliable HVAC solutions for your commercial HVAC installations. Contact us today!
